| RANGO DE OPERACIÓN |
| REF |
ESPIGO (L) |
DIÁMETRO DEL TUBO (D - mm) |
ESPESOR PARED (E-mm) |
TUBO |
IMC |
EMT |
| CP ½ |
1 |
21.3 |
4 |
1/2 |
20,96 |
17,80 |
| CP¾ |
1 |
26.7 |
4 |
3/4 |
26,46 |
23,29 |
| CP 1 |
1 |
33.4 |
4 |
1 |
33,28 |
29,41 |
| CP 1 ¼ |
1 ¼ |
42.2 |
4 |
1-1/4 |
41,81 |
38,35 |
| CP 1 ½ |
1 ½ |
48.3 |
4 |
1-1/2 |
48,04 |
44,07 |
| CP 2 |
2 |
60.3 |
4 |
2 |
60,20 |
55,67 |
| CP 3 |
3 |
88.9 |
4 |
3 |
88,57 |
88,52 |
| CP 4 |
3 |
112.6 |
4 |
4 |
113,79 |
113,79 |
